Throttle valves Danfoss VRC

VÆLG VARIANT
Varenummer Beskrivelse
820104119 820104119 - Prio.ventil tryckkompenserad 1-4l/m VRC 06-__-1.25
820104219 820104219 - Prio.ventil tryckkompensera 3-10l/m VRC 06-__-2.0
820104319 820104319 - Flödesventil 6-20l/m VRC 06-__-3.0
820104419 820104419 - Tryckreduceringsventil10-30l/m VRC 06-__-3.5
820106119 820106119 - Tryckreduceringsventil m.hus 1-4 l/m VRC 06-M-1.25-SE-1/2"
820171619 820171619 - Prio.ventil tryckkompenserad 25-60 l/m VRC 12-E-5.00-00
820172119 820172119 - Flödesventil tryckkompenserad16-40l/m VRC12E-4.00-00
820172219 820172219 - Flödesventil tryckkompenserad 25-60l/m VRC12-M-5.00-00
820196819 820196819 - Flödesventil tryckkompenserad 6-16l/m VRC12-E-2.50-00
820198019 820198019 - Flödesventil tryckkompenserad 9-32l/m VRC12-E-3.50-00
820212419 820212419 - Prio.ventil tryckkompenserad 30-73 l/m VRC12E-5.75-00
820219819 820219819 - Flödesventil tryckkompenserad 2.5-6.5l/m VRC12-E-1.25-00
Föroreningsgrad max.
20/18/14 - ISO 4406

Märke namn
Danfoss

Oljeviskositet rekommanderad
12 - 54

Temperatur max.
+100

Temperatur min.
-40

Tryck max.
315

Tryckkompenserad
Ja
