Pneufit 10 L-adaptor swiveling for mm tube to BSPP/MM

Pneufit 10 L-adaptor swiveling for mm tube to BSPP/MM

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Diameter pipe Thread Pressure max.
102680405 102680405 - Adapter L Ø4 mm Utv-M5, Vridbar 4 mm 20 bar
102680418 102680418 - Adapter L Ø4 mm Utv-G1/8'', Vridbar 4 mm G 1/8 BSP 20 bar
102680428 102680428 - Adapter L Ø4 mm Utv-G1/4'' Vridbar 4 mm G 1/4 BSP 20 bar
102680505 102680505 - Adapter L Ø5 mm Utv-M5, Vridbar 20 bar
102680518 102680518 - Adapter L Ø5 mm Utv-G1/8'', Vridbar 5 mm G 1/8 BSP 20 bar
102680618 102680618 - Adapter L Ø6 mm Utv-G1/8'', Vridbar 6 mm G 1/8 BSP 20 bar
102680628 102680628 - Adapter L Ø6 mm Utv-G1/4'', Vridbar 6 mm G 1/4 BSP 20 bar
102680818 102680818 - Adapter L Ø8 mm Utv-G1/8'', Vridbar 8 mm G 1/8 BSP 20 bar
102680828 102680828 - Adapter L Ø8 mm Utv-G1/4'', Vridbar 8 mm G 1/4 BSP 20 bar
102680838 102680838 - Adapter L Ø8 mm Utv-G3/8'', Vridbar 8 mm G 3/8 BSP 20 bar
102681028 102681028 - Adapter L Ø10 mm Utv-G1/4'', Vridbar 10 mm G 1/4 BSP 20 bar
102681038 102681038 - Adapter L Ø10 mm Utv-G3/8'', Vridbar 10 mm G 3/8 BSP 20 bar
102681228 102681228 - Adapter L Ø12 mm Utv-G1/4'', Vridbar 12 mm G 1/4 BSP 20 bar
102681238 102681238 - Adapter L Ø12 mm Utv-G3/8'', Vridbar 12 mm G 3/8 BSP 20 bar
102681248 102681248 - Adapter L Ø12 mm Utv-G1/2'' Vridbar 12 mm G 1/2 BSP 20 bar
102681438 102681438 - Adapter L Ø14 mm Utv-G3/8'', Vridbar 14 mm G 3/8 BSP 20 bar
102681448 102681448 - Adapter L Ø14 mm Utv-G1/2'', Vridbar 14 mm G 1/2 BSP 20 bar
Pressure max.
20
REACH compliant
Ja
RoHs compliant
Ja
Sealing material
NBR, POM (Acetal)
Standard
Silicone Free
Surface treatment
Förnicklad
Temperature max.
+80
Temperature min.
-20
Vacuum max.
-0.9
