PVG100 spolar

PVG100 spolar

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Flow rate nominal LMin
11013082 Slid PVBZ PVG100 CC 130 ltr. 130 lpm
11102189 Slid för högflödes sektion PVB PVG100 210l/m
161B7022 Slid PVBZ PVG100 40 lpm closed Progressiv 40 lpm
161B7023 Slid PVBS PVG100 65 lpm closed Progressiv 65 lpm
161B7024 Slid PVBZ PVG100 100 lpm A+B closed. med backventil 100 lpm
161B7025 Slid PVBZ PVG100 130 lpm A+B closed med backventil 130 lpm
161B7026 Slid PVBZ PVG100 150 lpm A+B closed med backventil 150 lpm
161B7027 Slid PVBZ PVG100 180 lpm A+B closed med backventil 180 lpm
161B7122 Slid PVBZ PVG100 40 lpm motor A+B closed med backventil 40 lpm
161B7123 Slid PVBZ PVG100 65 lpm A+B open med backventil 65 lpm
161B7124 Slid PVBZ PVG100 100 lpm motor A+B open med backventil 100 lpm
161B7125 Slid PVBZ PVG100 130 lpm motor A+B open med backventil 130 lpm
161B7126 Slid PVBZ PVG100 150 lpm motor A+B open med backventil 150 lpm
161B7127 Slid PVBZ PVG100 180 lpm motor A+B open med backventil 180 lpm
161B9625 Slid PVBZ PVG100 130 Lpm motor
Brand Name
Danfoss
Contamination level max.
23/19/16 - ISO 4406
Oil viscocity recommended
12 - 75
Pressure T max.
40
Pressure continous max.
350
Pressure intermittent max.
400
Pressure max.
350
Temperature max.
+90
Temperature min.
-30
