Adapter 45° 14S, Ställbar, O-ringstätad
M22x1.5-14
Partnumber:
XEV14S
Package size:
1 st
Min. order quantity is:
1 st
Angle
45 °
Brand Name
Stauff
Corrosion resistance
1200 hours salt spray DIN EN ISO 9227
D1
14 mm
D2
10 mm
Diameter pipe
14 mm
L
24 mm
L2
16 mm
L3
33,5 mm
Material
Stål
Model code
FI-EVD-14S-V-W3-DKO
PN
630 bar
Pressure max.
630 bar
REACH compliant
Ja
RoHs compliant
Ja
S1
22 mm
S2
27 mm
Safety factor
4
Sealing material
FKM/FPM (Viton®)
Series
S
Surface treatment
Zink-Nickel
Temperature max.
+200 °C
Temperature min.
-25 °C
Thread inner metric
M22x1,5
Thread outer metric
M22x1,5
Package size
1 st
Barcode
476729
Gross weight
Kg
Net weight
0,144 Kg
Country of origin
deu
Intrastat code
73071110
M22x1.5-14
