    • Pump S45 FR-L-074B-BS-31-20-NN-N-3-S1R2-A1N-AAA-NNN-NNN

    Pump S45 FR-L-074B-BS-31-20-NN-N-3-S1R2-A1N-AAA-NNN-NNN

    Artikelnummer:
    83017456
    Förpackningsstorlek:
    1 st
    Minsta beställningskvantitet:
    1 st
    AuxMount/EndCap code
    R2
    Brand Name
    Danfoss
    Contamination level max.
    22/18/13 - ISO 4406
    Continuous rotation max.
    2400 rpm
    Control
    Lastkännande
    Displacement
    74 cm3
    Displacement limiter
    Ingen
    Flange SAE/DIN
    3000 PSI
    Flange inlet
    2 "
    Flange outlet
    1 "
    Holes circle
    161.9 mm
    Model
    Frame F
    Model code
    FR-L-074B-BS-31-20-NN-N-3-S1R2-A1N-AAA-NNN-NNN
    Number of outer grooves
    14
    Oil viscocity recommended
    9 - 110 cSt
    Port position
    Sida
    Pressure continous max.
    310 bar
    Pressure max.
    400 bar
    Recess
    127,0 mm
    Rotation direction
    Höger (CW)
    Rotation max. at max. pressure
    2600 rpm
    Rotational speed max.
    2800 rpm
    Rotational speed min.
    500 rpm
    Shaft code
    S1
    Shaft diameter
    31,2 mm
    Shaft seal material
    FKM/FPM (Viton®)
    Shaft spline
    14T 12/24 SAE-C
    Temperature intermittent max.
    +104 °C
    Temperature max.
    +82 °C
    Temperature min.
    -40 °C
    Förpackningsstorlek
    1 st
    Streckkod
    334058
    Bruttovikt
    39,00 Kg
    Nettovikt
    39,00 Kg
    Ursprungsland
    Intrastat artikelkod
    84135061
