Orbit motor OMP-X 160 - 25mm shaft - drainport
Danfoss Orbital X replaces Danfoss OMP. With its unique modular platform and "shape & fit" with the O-series, the Orbital X can replace existing O-series motors in applications where these are required. The Orbital X has improved performance, reducing the "total cost of ownership."
The Orbital X offers up to 15% more torque than previous versions of the OMP. Stronger bearing capacity to withstand the higher radial loads of the application. All motors feature an improved HPS shaft seal, 225 bar. All motors have the option of a drain connection. All motors have check valves.
OMP-X is the top hydraulic motor in its class. With high and consistent quality, the motor is built for demanding applications, long life and exceptionally high efficiency over its lifetime.
If the need is not necessarily top class due to application or economic reasons, we can recommend alternatives from the Danfoss Value Line range, where motor types WP (OMP) and WR (OMR) are very reasonable options.
Artikelnummer:
11186705
Förpackningsstorlek:
1 st
Minsta beställningskvantitet:
1 st
Antal monteringshål
2
Arbetsportar
G 1/2 BSP
Axel diameter
25 mm
Axel kilspår
8,0 mm
Axeltyp
Cylindrical
Bultcirkel
106.4 mm
Deplacement
155.7 cm3
Dimension L
147.5 mm
Dräneringsport
G 1/4 BSP
Kont. rotation max.
385 rpm
Kontinuerlig effekt max.
11.2 kW
Moment kontinuerlig max.
335 Nm
Monteringsfläns
SAE-A2
Märke namn
White
Oljeviskositet rekommanderad
20 - 75 cSt
Portplacering
Side
Reces
82,5 mm
Tryckfall kontinuerlig max.
160 bar
Förpackningsstorlek
1 st
Streckkod
368813
Bruttovikt
6,70 Kg
Nettovikt
6,70 Kg
Ursprungsland
Intrastat artikelkod
84122981
Danfoss Orbital X replaces Danfoss OMP. With its unique modular platform and "shape & fit" with the O-series, the Orbital X can replace existing O-series motors in applications where these are required. The Orbital X has improved performance, reducing the "total cost of ownership."
The Orbital X offers up to 15% more torque than previous versions of the OMP. Stronger bearing capacity to withstand the higher radial loads of the application. All motors feature an improved HPS shaft seal, 225 bar. All motors have the option of a drain connection. All motors have check valves.
OMP-X is the top hydraulic motor in its class. With high and consistent quality, the motor is built for demanding applications, long life and exceptionally high efficiency over its lifetime.
If the need is not necessarily top class due to application or economic reasons, we can recommend alternatives from the Danfoss Value Line range, where motor types WP (OMP) and WR (OMR) are very reasonable options.
