    • Propo. paineenrajoitusventtiili NC

    Propo. paineenrajoitusventtiili NC

    250bar 76l/min 155-215bar 24VDCSDC10-2

    Artikelnummer:
    PRV10POC215C24DDEE
    Förpackningsstorlek:
    1 pcs
    Minsta beställningskvantitet:
    1 pcs
    Coil M19P-12D-1.8A-DE
    Partnumber: M19P-12D-1.8A-DE
    Coil M19P-12D-1.8A-DN
    Partnumber: M19P-12D-1.8A-DN
    Coil M19P-24D-0.9A-DE
    Partnumber: M19P-24D-0.9A-DE
    COIL, M19P-24D-0.9A-DN M19P-24D-0.9A-DN
    Partnumber: M19P-24D-0.9A-DN
    HOUSING, SDC10-2-DG4B (1/2) SDC10-2-DG4B (1/2)
    Partnumber: SDC10-2-DG4B
    Brand Name
    Danfoss
    Cavity
    SDC10-2
    Contamination level max.
    22/18/13 - ISO 4406
    Flow rate nominal LMin
    76 lpm
    Material
    Steel
    Oil viscocity recommended
    12 - 54 cSt
    Pressure max.
    250 bar
    Pressure setting max.
    215 bar
    Pressure setting min.
    155 bar
    Sealing material
    NBR
    Temperature max.
    +120 °C
    Temperature min.
    -30 °C
    Torque tightening
    45 - 50 Nm
    Package size
    1 pcs
    Barcode
    404894
    Gross weight
    0,536 Kg
    Net weight
    0,536 Kg
    Country of origin
    IT

    250bar 76l/min 155-215bar 24VDCSDC10-2

    Product datasheet
