Oil - air cooler hydraulic drive ASA 0257 11cm³ Hydr.motor

Oil - air cooler hydraulic drive ASA 0257 11cm³ Hydr.motor

Osanumero:

ASA0367AH11

Pakkauskoko:

1 pcs

Pienin tilausmäärä on:

1 pcs

Accessories (5)

Connector ASA AUC BSP1" 1/4"

Varenummer: ILLZASA32G32

ASA Series Connector intermediate plate NG 40

Varenummer: ILLZASA40-40G12

Temperature switch BSP1/2" DIN-3P Set point 50C

Varenummer: ILLZTH4765K

Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C

Varenummer: ILLZTH5069K

Temperature switch BSP1/2" DIN-3P Set point 60C

Varenummer: ILLZTH6065K

Specifikationer
Dimensioner og forsendelse

Brand Name

ASA

By-pass valve

Depth

430 mm

Flowrate nominal LMin

250 lpm

Height

720 mm

Material

Aluminium

Model code

ASA0367AH11

Noise level

73 dB-A

Pressure max.

26 bar

Temperature max.

+80 °C

Temperature min.

-20 °C

Width

762 mm

Pakke str.

1 pcs

Stregkode

504527

Brutto vægt

Netto vægt

44,50 Kg

Oprindelsesland

aut

Intrastat varekode

84186900

Produkt information

Oil - air cooler hydraulic drive ASA 0257 11cm³ Hydr.motor
