S220-16-27U adaptor UNF

Varenummer:

M-16-1.1/16

Pakke str.:

0 pcs

Min. bestillingsenhed er:

1 pcs

Tilbehør (2)

Bushing Ø16

Partnumber: B-16

Omløber 7/8-14 JIC Nøglevidde 27mm

Partnumber: J-14/16

Specifications
Dimensions and shipping

Angle

0 °

Brand Name

FOR

Corrosion resistance

1400 hours salt spray DIN EN ISO 9227

Diameter pipe

14-15-16 mm

Dimension A

47 mm

Dimension B

19.5 mm

Dimension CH

32 mm

Dimension D

15 mm

Dimension F

1.1/16-12 UNF

Dimension J

7/8-14 JIC

Dimension T

14-15-16 mm

Material

Steel

Pressure max.

350 bar

Surface treatment

Electro-galvanized / White chromatized

Thread outer

7/8-14 JIC

Thread outer

1.1/16-12 UNF

Package size

0 pcs

Barcode

5704334155829

Gross weight

0,15 Kg

Net weight

0,15 Kg

Country of origin

ITA

Intrastat code

73071110

Product information
Measure sketch

S220-16-27U adaptor UNF

Note: Opening 3D files requires a program that supports the file format
