OMH 500 HYDRAULIC MOTOR BLACK
OMH are light and compact and thus easy to install in machinery like forklifts, lawn mowers, lifts, loaders and excavators.
Partnumber:
151H1021
Package size:
1 st
Min. order quantity is:
1 st
Brand Name
White
Continuous power max.
11 kW
Continuous rotation max.
155 rpm
Dimension L
208.3 mm
Dimension L1
65 mm
Displacement
470.6 cm3
Drainport
G 1/4 BSP
Holes circle
106.4 mm
Mounting flange
SAE-A4 Magneto
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Pressure drop continuous max.
125 bar
Recess
82,5 mm
Sealing material
NBR
Shaft diameter
35 mm
Shaft keyway
10,0 mm
Shaft type
Cylindrical
Surface treatment
Painted black
Torque continuous max.
820 Nm
Working ports
G 1/2 BSP
Package size
1 st
Barcode
333856
Gross weight
13,57 Kg
Net weight
13,57 Kg
Country of origin
Intrastat code
84122981
OMH are light and compact and thus easy to install in machinery like forklifts, lawn mowers, lifts, loaders and excavators.
