Hand-Held PPC-PAD-PLUS-W Hydraulic Tester Basic Unit WLAN

The PPC-PAD-PLUS-W Multifunction Hand-Held Hydraulic Tester are developed especially for high demands and helps you to master these challenges.
It has never been so easy to track the complex processes in these industries through measurements, displays and analyses. Possible areas of application include preventive maintenance, commissioning, troubleshooting and machine optimization.


The PPC-PAD-PLUS-W has a 7" touch screen which makes operation very simple, even for complex tasks.
The modular design also ensures best possible adaptation to a variety of different measuring tasks. Different input modules are offered for connecting additional sensors. These modules can easily be replaced by the user. There is an option of running the basic device with max. two additional modules in the device.
The CAN Bus Sensors from STAUFF use the automatic sensor detection of the bus to allow an easy-to-install plug-and-play solution (max. CAN bus length 100 m/328 ft). The device is compatible with the existing sensors from the PPC Series.


One great advantage is the option to generate a variety of different templates for recurring measuring tasks and saving these in so-called containers. Calling up these templates for recurring measuring tasks ensures interpretation and comparability of the results at all times. This can even go so far as executing these templates automatically at the press of a button.
The integrated WIFI function also allows the device to be controlled via remote access, which means that executing measuring tasks and calling up the recorded data from a different location are no longer a challenge.
The PPC-Analyze PC Software offers additional methods for analysis, control and remote service using LAN and USB connections. In combination with this software, the PPC-PADplus is a very user-friendly hydraulic tester that is suitable for all types of diagnostic applications.


Includes:
• PPC-PAD-PLUS-W Datalogger
• Power supply 110 V/240 V – 24 V DC/2,5 A
• Adapter for power supply (EN, US, UK, AUS)
• 2 m USB 2.0 cable.
• Carrying strap for PPC-PAD-PLUS-W
• Instructions for use
• PC-software

Partnumber:
6100194744

Package size:
0 pcs

Min. order quantity is:
1 pcs
Temperatursensor M10x1
Partnumber: 1000257665
Pressure/Temp sensor 0 +600bar max1200, -25 +105°C, w.o.cabl
Partnumber: 1810000064
Kabel 3 m
Partnumber: 1810000066
Tryck & tempsensor PT
Partnumber: 1810000330
Tryck & tempsensor PT
Partnumber: 1810000332
Tryck & tempsensor PT
Partnumber: 1810000334
Pressure & Temp. sensor PT 600 Bar
Partnumber: 1810000336
Cable CAN 2 m
Partnumber: 1810000350
Cable CAN 5 m
Partnumber: 1810000351
Cable CAN 10 m
Partnumber: 1810000352
Cable PPC-CAN-CAB-Y
Partnumber: 1810000353
Terminating resistor PPC-CAN-R
Partnumber: 1810000354
Cable PPC-CAN-CAB20 CAN 20 m
Partnumber: 1810000377
Temperatursensor G1/4''
Partnumber: 1810000521
Kabel PPC övergång 4 pinnar till 5 pinnar, L= 2 meter
Partnumber: 1810010003
Trycksensor PPC
Partnumber: 1810010788
Trycksensor PPC
Partnumber: 1810010789
Trycksensor PPC
Partnumber: 1810010790
Trycksensor PPC
Partnumber: 1810010791
Use 1810010792
Partnumber: 1810010792
Pressure Sensor analogue -1 > 15bar
Partnumber: 1810010793
Trycksensor 60 Bar
Partnumber: 1810010794
Trycksensor 150 Bar
Partnumber: 1810010795
Trycksensor 400 Bar
Partnumber: 1810010796
Trycksensor PPC 04/12 600Bar
Partnumber: 1810010797
Trycksensor 400 Bar kalibrerad
Partnumber: 1810010807
Power Supply Unit (110/230 V AC) for PPC-PAD-PLUS
Partnumber: 6100194731
Input Module for PPC-PAD-PLUS Connection of 2 CAN Channels
Partnumber: 6100194735
Input Modul Analog PPC-PAD-PLUS Galvanic
Partnumber: 6100194737
In car charger adaptor SR-HPM-CHG-03-0C
Partnumber: FT9863
Height
60 mm

Length
282 mm

Model code
PPC-PAD-PLUS-W

Sensor type
Analog, CAN

Temperature max.
+50 °C

Temperature min.
-10 °C

Width
154 mm
Package size
0 pcs

Barcode
5704334847526

Gross weight
Kg

Net weight
3,326 Kg

Country of origin
deu

Intrastat code
90262040
