    • Coupling Hansen (ISO-B) - female DN06 - G1/4"

    Coupling Hansen (ISO-B) - female DN06 - G1/4"

    Quick-coupling with ball-lock.

    Artikelnummer:
    2H16
    Förpackningsstorlek:
    0 pcs
    Minsta beställningskvantitet:
    1 pcs
    Coupling Hansen (ISO-B) - male DN06 - G1/4"
    Partnumber: 2-K16-BS
    Dammskydd HNV Hona, Röd
    Partnumber: TMH14R
    Snabbkoppling Iso-B, Hona, Inv-G1/4''
    Partnumber: HNV14GASF
    sealkit female HNV14 (10) o-ring + antiextrusion
    Partnumber: SKHNV14
    Packningssats 1st oring+ 1 st stödring FKM 1/4''
    Partnumber: SKHNV14V
    Brand Name
    Danfoss
    DN
    6 mm
    Dimension A
    57.4 mm
    Dimension B
    29 mm
    Flow rate nominal LMin
    12 lpm
    Hexagon
    19.1 mm
    ISO size
    6.3
    Material
    Steel
    Model code
    2H16BS
    Pressure eliminator
    No
    Pressure max.
    345 bar
    Sealing material
    NBR
    Size
    1/4 "
    Standard ISO
    ISO 7241-1-B
    Surface treatment
    Electro zinc plated
    Temperature max.
    +121 °C
    Temperature min.
    -40 °C
    Thread inner
    G 1/4 BSP
    Package size
    0 pcs
    Barcode
    5704295707860
    Gross weight
    0,13 Kg
    Net weight
    0,13 Kg
    Country of origin
    FRA
    Intrastat code
    84812010

    Quick-coupling with ball-lock.

    Technical data
