OMSS 250 HYDRAULIC MOTOR

OMSS = Short version without front bearing and shaft for direct mounting on a gear. An orbital motor combined with a gear ensures a smooth and steady operation at very low speed high torque.

Artikelnummer:
151F0540

Förpackningsstorlek:
0 pcs

Minsta beställningskvantitet:
1 pcs
Ventilblock motormont. MM-OMS-00-DCP441-1-B-4B-E-B-XXX-4
Partnumber: 83004639
Brake RF2/43/DG-RF/289 Input OMSS Output OMS ø32
Partnumber: 154-2852
Bremse RF2/43/DG-RF/290 Input OMSS Output OMSW ø36
Partnumber: 154-2857
Bremse RF2/60/DG-RF/289 Input OMSS - Output OMS.
Partnumber: 154F3353
Brand Name
White

Continuous power max.
14.5 kW

Continuous rotation max.
300 rpm

Dimension L
154 mm

Dimension L1
43.5 mm

Dimension L2
112 mm

Displacement
250 cm3

Drainport
G 1/4 BSP

Holes circle
125 mm

Mounting flange
Short 100

Number of mounting holes
4

Oil viscocity recommended
20 - 75 cSt

Pressure drop continuous max.
200 bar

Recess
100,0 mm

Torque continuous max.
720 Nm

Working ports
G 1/2 BSP
Package size
0 pcs

Barcode
5704295499062

Gross weight
10,32 Kg

Net weight
10,32 Kg

Country of origin

Intrastat code
84122981

OMSS = Short version without front bearing and shaft for direct mounting on a gear. An orbital motor combined with a gear ensures a smooth and steady operation at very low speed high torque.
