    • Coupling Hansen (ISO-B) - male DN40 - G1.1/2"

    Coupling Hansen (ISO-B) - male DN40 - G1.1/2"

    Quick-coupling with ball-lock.

    Artikelnummer:
    12K46
    Förpackningsstorlek:
    0 pcs
    Minsta beställningskvantitet:
    1 pcs
    Coupling Hansen (ISO-B) - female DN40 - G1.1/2"
    Artikelnummer: 12H46
    Brand Name
    Danfoss
    DN
    40 mm
    Dimension C
    120.9 mm
    Dimension D
    69.6 mm
    Dimension E
    67.8 mm
    Flow rate nominal LMin
    375 lpm
    Hexagon
    60.5 mm
    ISO size
    40
    Material
    Steel
    Model code
    12K46BS
    Pressure eliminator
    No
    Pressure max.
    150 bar
    Sealing material
    NBR
    Size
    1.1/2 "
    Standard ISO
    ISO 7241-1-B
    Surface treatment
    Electro zinc plated
    Temperature max.
    +100 °C
    Temperature min.
    -25 °C
    Thread inner
    G 1.1/2 BSP
    Förpackningsstorlek
    0 pcs
    Streckkod
    5704295553603
    Bruttovikt
    1,34 Kg
    Nettovikt
    1,34 Kg
    Ursprungsland
    FRA
    Intrastat artikelkod
    73079910

    Quick-coupling with ball-lock.

    Technical data
