Ball valve 3 way - Standard series, BSP, L-bore, steel, without mounting holes - BK3

Ball valve 3 way - Standard series, BSP, L-bore, steel, without mounting holes - BK3

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Pressure max. Diameter inner Thread
BK3-1/2L 3-way valve-female 1/2 B BK3 G1/2 13 1123 1 l 350 bar 13 mm G 1/2 BSP
BK3-1/2LA 3-way valve-female 1/2 B BK3 G1/2 13 1123 1 la 350 bar 13 mm G 1/2 BSP
BK3-1/2PA 3-way valve-female 1/2 B BK3 G1/2 13 1123 1 PA 350 bar 13 mm G 1/2 BSP
BK3-1/4L 3-way valve-female 1/4 B BK3 G1/4 06 1123 1 l 400 bar 6 mm G 1/4 BSP
BK3-1/4LA 3-way valve-female 1/4 B BK3 G1/4 06 1123 1 la 400 bar 6 mm G 1/4 BSP
BK3-1/4PA 3-way valve-female 1/4" BK3 G1/4 06 1123 1 PA 400 bar 6 mm G 1/4 BSP
BK3-3/8L 3-way valve-female 3/8 B BK3 G3/8 10 1123 1 l galvaniz 400 bar 9 mm G 3/8 BSP
BK3-3/8LA 3-way valve-female 3/8 B BK3 G3/8 10 1123 1 la 400 bar 9 mm G 3/8 BSP
BK3-3/8PA 3-way valve-female 3/8 B BK3 G3/8 10 1123 1 PA 400 bar 9 mm G 3/8 BSP
Brand Name
Pister Kugelhähne
Number of ways/positions
3/2
Temperature max.
+60
Temperature min.
-20
