OMM 8,0 HYDRAULIC MOTOR
OMM and OML are ideal for use in industrial applications as well as the mobile sector, eg. mobile conveyors for agricultural machinery.
Partnumber:
151G0041
Package size:
0 pcs
Min. order quantity is:
1 pcs
Brand Name
White
C
M6
Continuous power max.
1.8 kW
Continuous rotation max.
1950 rpm
D
G 3/8 BSP
Displacement
8.2 cm3
Drainport
G 1/8 BSP
E
G 1/8 BSP
Holes circle
45 mm
Intermittent Rotation speed Max.
2450
Intermittent Torque Max.
15 Nm
L
104 mm
L1
3,5 mm
Mounting flange
OMM 45
Number of mounting holes
3
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Power max.
2.6 kW
Pressure continous max.
140 bar
Pressure drop continuous max.
100 bar
Pressure intermittent max.
175 bar
Pressure peak max.
225 bar
Recess
31,5 mm
Rotational speed max.
2450 rpm
Sealing material
NBR
Shaft diameter
16 mm
Shaft keyway
5,0 mm
Shaft spline
DIN 6885
Shaft type
Cylindrical
Torque continuous max.
11 Nm
Torque output max.
15 Nm
Working ports
G 3/8 BSP
Package size
0 pcs
Barcode
5704295162133
Gross weight
2,14 Kg
Net weight
2,14 Kg
Country of origin
Intrastat code
84122981
OMM and OML are ideal for use in industrial applications as well as the mobile sector, eg. mobile conveyors for agricultural machinery.
