Walvoil VODL

Double overcentervalve 3/8" VODL/N1116/38/G5.p4/ac

Double overcentervalve 1/2" VODL/N1116/12/G5.p4/ac, 50-350 b

Double overcentervalve 1/2 VODL/N1516/12/G5.p4.PR/ac

Double overcentervalve 3/4 VODL/N1516/34/G5.p4.PR/ac

D. overcenter m/bremseløft 3/4" V-VODL/SC/A 34/TR.S.p3.PG/ac

SELECT VARIANT

Partnumber	Description	Flow rate nominal LMin	Thread	Pilot ratio	Pressure max.
1554322100	Double overcentervalve 3/8" VODL/N1116/38/G5.p4/ac	60 lpm	G 3/8 BSP	1:4	350 bar
1554332100	Double overcentervalve 1/2" VODL/N1116/12/G5.p4/ac, 50-350 b	60 lpm	G 1/2 BSP	1:4	350 bar
1556532101	Double overcentervalve 1/2 VODL/N1516/12/G5.p4.PR/ac	160 lpm	G 1/2 BSP	1:4	350 bar
1556542100	Double overcentervalve 3/4 VODL/N1516/34/G5.p4.PR/ac	160 lpm	G 3/4 BSP	1:4	350 bar
1561042101	D. overcenter m/bremseløft 3/4" V-VODL/SC/A 34/TR.S.p3.PG/ac	150 lpm	G 3/4 BSP	1:4	350 bar

Brand Name

Walvoil

Contamination level max.

18/16/13 - ISO 4406

Material

Steel

Oil viscocity recommended

10 - 200

Pilot ratio

1:4

Pressure max.

350

Sealing material

NBR

Temperature max.

+80

Temperature min.

-20
