L-fitting - L-series - Male x Male x BSPT male - D-RLX / XLE-LKR

L-fitting - L-series - Male x Male x BSPT male - D-RLX / XLE-LKR

Välj variant
VÄLJ VARIANT
VÄLJ VARIANT
Artikelnummer Beskrivning Diameter pipe Pressure max. Thread outer metric Thread outer
D06RLX L stud ø6L x 1/8" BSPT 6 mm 315 bar M12x1,5 R 1/8 BSPT
D08RLX L stud ø8L x 1/4" BSPT 8 mm 315 bar M14x1,5 R 1/4 BSPT
D10RLX L stud ø10L x 1/4" BSPT 10 mm 315 bar M16x1,5 R 1/4 BSPT
D12RLX L stud ø12L x 3/8" BSP 12 mm 315 bar M18x1,5 R 3/8 BSPT
D15RLX L stud ø15L x 1/2" BSP 15 mm 315 bar M22x1,5 R 1/2 BSPT
D18RLX L stud ø18L x 1/2" BSP 18 mm 315 bar M26x1,5 R 1/2 BSPT
D22RLX L stud ø22L x 3/4" BSP 22 mm 160 bar M30x2 R 3/4 BSPT
FXLE08LR14K L stud ø8L x 1/4" BSPT 8 mm 315 bar M14x1,5 R 1/4 BSPT
FXLE10LR14K L stud ø10L x 1/4" BSPT 10 mm 315 bar M16x1,5 R 1/4 BSPT
FXLE12LR38K L stud ø12L x 3/8" BSP 12 mm 315 bar M18x1,5 R 3/8 BSPT
FXLE15LR12K L stud ø15L x 1/2" BSP 15 mm 315 bar M22x1,5 R 1/2 BSPT
FXLE16SR12K L stud ø16S x 1/2" BSPT 16 mm 315 bar R 1/2 BSPT
FXLE18LR12K L stud ø18L x 1/2" BSPT 18 mm 315 bar R 1/2 BSPT
Corrosion resistance
1200 hours salt spray DIN EN ISO 9227
Material
Steel
Safety factor
4
Series
L
Surface treatment
Zinc-Nickel plated
Temperature max.
+120
Temperature min.
-40
