Orbital motors White OMSS

Orbital motors White OMSS

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Displacement Shaft type Continuous power max. Pressure continous max.
151F0535 OMSS 80 HYDRAULIC MOTOR Series 3 80.5 cm3 Spline 16 kW 230 bar
151F0536 OMSS 100 HYDRAULIC MOTOR Series 3 100 cm3 Spline 17.5 kW 230 bar
151F0539 OMSS 200 HYDRAULIC MOTOR Series 3 200 cm3 Spline 16 kW 230 bar
151F0540 OMSS 250 HYDRAULIC MOTOR 250 cm3 Spline 14.5 kW 230 bar
151F0541 OMSS 315 HYDRAULIC MOTOR Series 3 314.9 cm3 Spline 15 kW 230 bar
Brand Name
White
C
G 1/4 BSP
D
M10
Drainport
G 1/4
E
G 1/2 BSP
Holes circle
125
Mounting flange
Short 100
Number of mounting holes
4
Oil viscocity recommended
20 - 75
Port position
Side
Pressure continous max.
230
Pressure intermittent max.
295
Pressure peak max.
300
Recess
100,0
Shaft type
Spline
Working ports
G 1/2
