Stauff ZP push/pull - up to 250 bar - ISO-A

Coupling female ZP (ISO-A) - DN12 - 1/2"BSP female

Coupling female ZP (ISO-A) - DN12 - M22x1.5 female

Coupling female ZP (ISO-A) - DN12 - M18x1.5 (12L)

Coupling female ZP (ISO-A) - DN12 - M22x1.5 (15L)

Coupling female ZP (ISO-A) - DN12 - M18x1.5 (12L) bulkhead

Coupling female ZP (ISO-A) - DN12 - M22x1.5 (15L) bulkhead

VÄLJ VARIANT

Artikelnummer	Beskrivning	Brand Name	Size	Pressure max.	Thread inner
ZP10-1-IGF08	Coupling female ZP (ISO-A) - DN12 - 1/2"BSP female	Stauff	1/2 "	250 bar	G 1/2 BSP
ZP10-1-IMF22	Coupling female ZP (ISO-A) - DN12 - M22x1.5 female	Stauff	1/2 "	250 bar
ZP10-1-L1218	Coupling female ZP (ISO-A) - DN12 - M18x1.5 (12L)	Stauff	1/2 "	250 bar
ZP10-1-L1522	Coupling female ZP (ISO-A) - DN12 - M22x1.5 (15L)	Stauff	1/2 "	250 bar
ZP10-1-N1218	Coupling female ZP (ISO-A) - DN12 - M18x1.5 (12L) bulkhead	Stauff	1/2 "	250 bar
ZP10-1-N1522	Coupling female ZP (ISO-A) - DN12 - M22x1.5 (15L) bulkhead	Stauff	1/2 "	250 bar

Brand Name

Stauff

Dimension X

Flow rate nominal LMin

100

ISO size

12.5

Pressure max.

250

Sealing material

NBR

Size

1/2

Standard ISO

ISO 7241-1-A

Temperature max.

+100

Temperature min.

-20
