LDC-011-B-0-00-S50-0-Z Cooler 150 l/min-0.30 kW/ C 2
Olaer oil cooler with DC motors.
Material of the cooling element: aluminum.
Oil connections: G 1"
Intake port: Bottom
Exhaust port: Top
The indicated flow and pressure values are maximum values and must not be exceeded.
The flow and cooling values are given with oil viscosity ISO VG 46 and 60 °C.
Varenummer:
5827011172
Pakke str.:
0 pcs
Min. bestillingsenhed er:
1 pcs
Brand Name
Hydraspecma
By-pass valve
Yes
By-pass valve
5 bar
Cooling effect at 40°C difference
12 kW
Cooling efficiency
0.3 kW/°C
Current max.
10 A
Current type
DC
Flow rate nominal LMin
150 lpm
Noise level
74 dB-A
Pressure max.
14 bar
Pressure static max.
21 bar
Rotational speed max.
3060 rpm
Temperature working fluid max.
+120 °C
Thread inner
G 1 BSP
Voltage
24 V
Pakke str.
0 pcs
Stregkode
5704334606994
Brutto vægt
14,00 Kg
Netto vægt
14,00 Kg
Oprindelsesland
POL
Intrastat varekode
84186900
Olaer oil cooler with DC motors.
Material of the cooling element: aluminum.
Oil connections: G 1"
Intake port: Bottom
Exhaust port: Top
The indicated flow and pressure values are maximum values and must not be exceeded.
The flow and cooling values are given with oil viscosity ISO VG 46 and 60 °C.
