L-forskruning stilbar 9/16-18 JIC udv x 1/4 BSP udv NW19

L-forskruning stilbar 9/16-18 JIC udv x 1/4 BSP udv NW19

Varenummer:

TOD-10-1/4

Pakke str.:

0 pcs

Min. bestillingsenhed er:

1 pcs

Specifications
Dimensions and shipping

Diameter rør

10 mm

Dimension B

27 mm

Dimension B1

27 mm

Dimension C

31.5 mm

Dimension CH

19 mm

Dimension F

G 1/4 BSP

Dimension J

9/16-18 JIC

Dimension J1

9/16-18 JIC

Dimension T

10 mm

Dimension T1

10 mm

Gevind udvendig

9/16-18 JIC

Gevind udvendig

G 1/4 BSP

Korrosions resistens

1400 hours salt spray DIN EN ISO 9227

Materiale

Stål

Mærke navn

FOR

Overfladebehandling

El-forzinket / hvidkromatiseret

Tryk maks.

350 bar

Package size

0 pcs

Barcode

5704295980980

Gross weight

0,07 Kg

Net weight

0,07 Kg

Country of origin

ITA

Intrastat code

73071110

Product information
Measure sketch

L-forskruning stilbar 9/16-18 JIC udv x 1/4 BSP udv NW19

Note: Opening 3D files requires a program that supports the file format
