Swivel elbow 90° - BSP male x BSP female - T-KRAW-IW

Swivel elbow 90° - BSP male x BSP female - T-KRAW-IW

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Thread outer Thread inner Pressure max. Rotational speed max.
9100-04 Swivel 1/4 BSP 400 bar Hydr. Male x female elbow G 1/4 BSP G 1/4 BSP 400 bar 6 rpm
9100-06 Swivel 3/8 BSP 400 bar Hydr. Male x female elbow G 3/8 BSP G 3/8 BSP 400 bar 6 rpm
9100-08 Swivel 1/2 BSP 300 bar Hydr. Male x female elbow G 1/2 BSP G 1/2 BSP 300 bar 6 rpm
9100-12 Swivel 3/4 BSP 300 bar Hydr. Male x female elbow G 3/4 BSP G 3/4 BSP 300 bar 6 rpm
9100-16 Swivel 1 BSP 300 bar Hydr. Male x female elbow G 1 BSP G 1 BSP 100 bar 6 rpm
9100-20 Swivel 1.1/4 BSP 100 bar Hydr. 60rpm., -20c/+100c. G 1.1/4 BSP G 1.1/4 BSP 80 bar 6 rpm
9100-24 Swivel 1.1/2 BSP 80 bar Hydr., 60rpm, -20c/+100c. G 1.1/2 BSP G 1.1/2 BSP 80 bar 6 rpm
9100-32 Swivel 2 BSP 50 bar Hydraulics 60 rpm G 2 BSP G 2 BSP 50 bar 6 rpm
Angle
90
Brand Name
I.M.M Hydraulics
Material
Steel
Rotational speed max.
6
Surface treatment
Electro-galvanized / White chromatized
Temperature max.
+100
Temperature min.
-20
