NS0606NJ
|
3/8" Insert (No-Skive) - 9/16"-18 JIC nut - 0901N06-06 |
9/16-18 JIC |
3/8 " |
0 ° |
For separate ferrule |
|
|
NS0608NJ
|
3/8" Insert (No-Skive) - 3/4"-16 JIC nut - 0901N06-08 |
3/4-16 JIC |
3/8 " |
0 ° |
For separate ferrule |
|
|
NS0808NJ
|
1/2" Insert (No-Skive) - 3/4"-16 JIC nut - 0901N08-08 |
3/4-16 JIC |
1/2 " |
0 ° |
For separate ferrule |
|
|
NS0810NJ
|
1/2" Insert (No-Skive) - 7/8"-14 JIC nut - 0901N08-10 |
7/8-14 JIC |
1/2 " |
0 ° |
For separate ferrule |
|
|
NS1010NJ
|
5/8" Insert (No-Skive) - 7/8"-14 JIC nut - 0901N10-10 |
7/8-14 JIC |
5/8 " |
0 ° |
For separate ferrule |
|
|
NS1212NJ
|
3/4" Insert (No-Skive) - 1.1/16"-12 JIC nut - 0900N12-12 |
1.1/16-12 JIC |
3/4 " |
0 ° |
For separate ferrule |
|
|
NS1616NJ
|
1" Insert (No-Skive) - 1.5/16"-12 JIC nut - 0900N16-16 |
1.5/16-12 JIC |
1 " |
0 ° |
For separate ferrule |
|
|
NS2020NJ
|
1.1/4" Insert (No-Skive) - 1.5/8"-12 JIC nut - 0900N20-20 |
1.5/8-12 JIC |
1.1/4 " |
0 ° |
For separate ferrule |
|
|
NS2424NJ
|
1.1/2" Insert (No-Skive) - 1.7/8"-12 JIC nut - 0900N24-24 |
1.7/8-12 JIC |
1.1/2 " |
0 ° |
For separate ferrule |
