Pressure relief valves Walvoil VMP

Pressure relief valves Walvoil VMP

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Flow rate nominal LMin Pressure setting min. Pressure setting max. Pressure max.
144303130 VMP10/3(XG-120) 1/2 BSP Walvoil pilot adting valve 50-350 b 60 lpm 50 bar 350 bar 315 bar
146303130 VMP20/3(XG-120) 3/4 BSP Walvoil, 60-250 bar 140 lpm 60 bar 250 bar 315 bar
147303130 VMP25/3(XG-120) 1 BSP Walvoil 240 lpm 25 bar 315 bar 315 bar
Brand Name
Walvoil
Contamination level max.
18/16/13 - ISO 4406
Material
Steel
Oil viscocity recommended
12 - 400
Pressure max.
315
