Blind flanges w/o O-ring - SAE 6000 PSI

Closed flange 1/2" SAE6000

Closed flange 3/4" SAE6000

Closed flange 1" SAE6000

Closed flange 1.1/4" SAE6000

Closed flange 1.1/2" SAE6000

Closed flange 2" SAE6000

SELECT VARIANT

Partnumber	Description	Flange	O-ring	Pressure max.
GFC401	Closed flange 1/2" SAE6000	1/2 "	18,64X3,53 mm	420 bar
GFC402	Closed flange 3/4" SAE6000	3/4 "	24,99X3,53 mm	420 bar
GFC403	Closed flange 1" SAE6000	1 "	32,93X3,53 mm	420 bar
GFC404	Closed flange 1.1/4" SAE6000	1.1/4 "	37,69X3,53 mm	420 bar
GFC405	Closed flange 1.1/2" SAE6000	1.1/2 "	47,22X3,53 mm	420 bar
GFC406	Closed flange 2" SAE6000	2 "	56,75X3,53 mm	420 bar

Brand Name

Havit

Corrosion resistance

480 hours salt spray DIN EN 9227

Flange SAE/DIN

6000 PSI

Material

Steel

Pressure max.

420

Shore

Standard ISO

ISO 6162-2

Standard SAE

SAE J518 Code 62

Surface treatment

Zinc-Nickel plated

Temperature max.

+90

Temperature min.

-40
