1/4" pressure gauge. Rear mount. Scale 0-1.6 bar
Application: Measuring pressure in hydraulic oil and gaseous fluids which are non-aggresive to copper alloys.
Glycerine dampened.
Comes standard with dual scale showing both bar and PSI.
U-bolt or flange mounting kit optional.
!!NOTE: Mounting hole diameter: ø67 mm +/-0,3 mm.
Artikelnummer:
SPG063-1.6RB
Förpackningsstorlek:
0 pcs
Minsta beställningskvantitet:
1 pcs
B
54 mm
C
15 mm
Diameter
63 mm
E
32 mm
F
6,5 mm
Glastyp
Acrylic glass
Gänga
G 1/4 BSP
Materialkvalitet
1.4301 / AISI304
Modell kod
SPG-063-00001.6-01-P-B04
Märke namn
Stauff
Portplacering
Rear
Skyddsklass
IP 65
Standard EN
EN 837-1
Temperatur max.
+60 °C
Temperatur min.
-20 °C
Tillverkningsmaterial
Stainless steel
Tryckinställning max.
1.6 bar
Tryckinställning min.
0 bar
Tryckmätning noggrannhet
±1,6% FS
ØA
69 mm
ØD
G 1/4 BSP
Package size
0 pcs
Barcode
5704295747316
Gross weight
0,23 Kg
Net weight
0,23 Kg
Country of origin
DEU
Intrastat code
90262040
Application: Measuring pressure in hydraulic oil and gaseous fluids which are non-aggresive to copper alloys.
Glycerine dampened.
Comes standard with dual scale showing both bar and PSI.
U-bolt or flange mounting kit optional.
!!NOTE: Mounting hole diameter: ø67 mm +/-0,3 mm.
