Cetop3 check valve, T port, 0,5 bar

Cetop3 check valve, T port, 0,5 bar

Partnumber:
HR016

Package size:
0 pcs

Min. order quantity is:
1 pcs
DHL-0711-00-DC
Partnumber: DHL0711-X
Brand Name
Atos

Contamination level max.
20/18/15 - ISO 4406

Flow rate nominal LMin
60 lpm

Model code
HR-016

NG ISO-size
NG06

Oil viscocity recommended
15 - 100 cSt

Pilot ratio
3,3:1

Pressure max.
350 bar

Pressure opening
0.5 bar

Standard ISO
ISO 4401

Temperature max.
+80 °C

Temperature min.
-20 °C
Package size
0 pcs

Barcode
5704295815244

Gross weight
0,79 Kg

Net weight
0,79 Kg

Country of origin
ITA

Intrastat code
84812010

Cetop3 check valve, T port, 0,5 bar
