Gear pump Casappa Grp3 51.83ccm 1:8 shaft - Right

Casappa Polaris, series 3 gear pump..

Housing: Aluminium..

Gear wheels with slide bearings and two aluminium end plates..

Front- and rear cover: Cast iron.

Connection flanges must be ordered separately.

Partnumber:
30.51D

Package size:
0 pcs

Min. order quantity is:
1 pcs
Straight flange 3/4" BSP - (4) 40mm
Partnumber: 2RD3/4X40
Flange 90° 3/4" BSP - (3) 40mm
Partnumber: 2RG3/4X40
Flange 90° 1" BSP - (3) 51mm
Partnumber: 3RG1X51
Threaded flange 1" BSP - (4) 51mm
Partnumber: FI1X51
Rear cover PLP30 Casappa
Partnumber: 21919800
Brand Name
Casappa

Contamination level max.
19/17/14 - ISO 4406

Displacement
51.83 cm3

Model code
PLP30.51D0-83E3-LED/EB-N-FS

Mounting flange
EU51 - 128x98

Number of mounting holes
4

Oil viscocity recommended
12 - 100 cSt

Port inlet
EU51

Port outlet
EU40

Pressure continous max.
210 bar

Pressure intermittent max.
230 bar

Pressure peak max.
240 bar

Pump group
3

Recess
51,0 mm

Rotation direction
Right (CW)

Rotational speed max.
2500 rpm

Shaft cone
1:8

Shaft keyway
4,0 mm

Shaft type
Tapered

Torque input
7 daNm
Package size
0 pcs

Barcode
5704295808819

Gross weight
9,78 Kg

Net weight
9,78 Kg

Country of origin
ITA

Intrastat code
84136031

Casappa Polaris, series 3 gear pump..

Housing: Aluminium..

Gear wheels with slide bearings and two aluminium end plates..

Front- and rear cover: Cast iron.

Connection flanges must be ordered separately.
