TOD-16-7/8 - L-forskruning stilbar 7/8-14 JIC udv x 7/8-14 UNF udv
L-forskruning stilbar 7/8-14 JIC udv x 7/8-14 UNF udv
Partnumber:
TOD-16-7/8
Package size:
0 pcs
Min. order quantity is:
1 pcs
B
36,5 mm
B1
36,5 mm
Brand Name
FOR
C
43 mm
CH
27 mm
Corrosion resistance
1400 hours salt spray DIN EN ISO 9227
Diameter pipe
16 mm
Dimension F
7/8-14 UNF
Dimension J1
7/8-14 JIC
J
7/8-14 JIC
Material
Stål
Pressure max.
350 bar
Surface treatment
El-forzinket / hvidkromatiseret
T
16 mm
T1
16 mm
Thread outer
7/8-14 JIC
Thread outer
7/8-14 UNF
Package size
0 pcs
Barcode
5704334274841
Gross weight
0,21 Kg
Net weight
0,21 Kg
Country of origin
ITA
Intrastat code
73071110
L-forskruning stilbar 7/8-14 JIC udv x 7/8-14 UNF udv
