1.1/4" Indstik - (35L) M45x2 oml.
Tilslutning: Indvendigt MM-gevind med 24° udadvendt konus og o-ring.
Pakning/tætningsflade: O-ring (gummi) mod konus (metal).
Partnumber:
GS2035RO45B
Package size:
0 pcs
Min. order quantity is:
1 pcs
A
132,5 mm
Angle
0 °
B
61,4 mm
Brand Name
Gates
Corrosion resistance
500 hours salt spray ASTM B-117
D
1.1/4 BSP
Diameter pipe
35 mm
H
50 mm
Hose coupling type
Til løs kappe
Hose size
1.1/4 "
Material
Stål
Model code
20GS-35FDLORX
REACH compliant
Ja
RoHs compliant
Ja
Sealing material
NBR
Series
L
Surface treatment
TuffCoat™
Temperature max.
+100 °C
Temperature min.
-35 °C
Torque tightening
205 - 225 Nm
Package size
0 pcs
Barcode
5704295983578
Gross weight
0,76 Kg
Net weight
0,76 Kg
Country of origin
CZE
Intrastat code
73269098
Tilslutning: Indvendigt MM-gevind med 24° udadvendt konus og o-ring.
Pakning/tætningsflade: O-ring (gummi) mod konus (metal).
Note: Opening 3D files requires a program that supports the file format
