Stuksvejseflange 1.1/2" SAE6000
Stuksvejseflange 1.1/2" SAE6000
Partnumber:
GFS405ST
Package size:
0 pcs
Min. order quantity is:
1 pcs
Angle
0 °
Brand Name
Havit
Diameter Weld butt
48.6 mm
Diameter flange
63.5 mm
Dimension C
79.3 mm
Dimension E
36.5 mm
Flange
1.1/2 "
Flange SAE/DIN
6000 PSI
Material
Stål
O-ring
47.22X3.53 mm
Pressure max.
250 bar
Shore
90
Standard ISO
ISO 6162-2
Standard SAE
SAE J518 Code 62
Temperature max.
+90 °C
Temperature min.
-40 °C
Thread of bolt metric
M16
Pakke str.
0 pcs
Stregkode
5704295321059
Brutto vægt
1,65 Kg
Netto vægt
1,65 Kg
Oprindelsesland
DEU
Intrastat varekode
73079100
Stuksvejseflange 1.1/2" SAE6000
