MUP-16 - Skotforskruning 7/8-14 JIC udv x 7/8-14 JIC udv
Skotforskruning 7/8-14 JIC udv x 7/8-14 JIC udv
Artikelnummer:
MUP-16
Förpackningsstorlek:
0 pcs
Minsta beställningskvantitet:
1 pcs
Angle
0 °
Brand Name
FOR
Corrosion resistance
1400 hours salt spray DIN EN ISO 9227
Diameter pipe
16 mm
Dimension A
69.5 mm
Dimension B
19.5 mm
Dimension CH
30 mm
Dimension CH1
30 mm
Dimension D
41 mm
Dimension J
7/8-14 JIC
Dimension J1
7/8-14 JIC
Dimension T
16 mm
Dimension T1
16 mm
Material
Stål
Pressure max.
350 bar
Surface treatment
El-forzinket / hvidkromatiseret
Thread outer
7/8-14 JIC
Package size
0 pcs
Barcode
5704334235460
Gross weight
0,17 Kg
Net weight
0,17 Kg
Country of origin
ITA
Intrastat code
73071110
Skotforskruning 7/8-14 JIC udv x 7/8-14 JIC udv
