S191-3 KULVENTIL LÅGTRYCK 3"
Ball valve in nickel-plated brass
with full flow for non-corrosive media such as water, compressed air, oils and petroleum.
Thread ISO 7/1 UNI-EN 10226
Temperature -20°C to +140°C
From PN80 (1/4") to PN16 (4)
Housing in brass CW617N UNI-EN 12165
Ball in chrome-plated brass CW614N UNI-EN 12164
Seat and other seals in PTFE
Handle in plastic-coated aluminum AL UNI5076
Varenummer:
S191-3
Pakke str.:
1 st
Min. bestillingsenhed er:
1 st
Aktivering
Manual
Antal väger/positioner
2/2
Användingsområde
Air, Diesel, Gasoline, Grease, Hydraulic oil, Water
Gänga
G 3 BSP
Gänge EN standard
EN 10226-1
Gängform
Female x female
Handtag
Inclusive
Handtaktyp
Angled
Materialkvalitet
CW614N/CW617N
Modell kod
S0191N41
Märke namn
Enolgas
Packningsmaterial
PTFE (Teflon®)
Standard EN
EN 13828
Temperatur max.
+140 °C
Temperatur min.
-20 °C
Tillverkningsmaterial
Brass
Tryck max.
25 bar
Ytskiktbehandling
Nickel-plated
Förpackningsstorlek
1 st
Streckkod
180260
Bruttovikt
Kg
Nettovikt
Kg
Ursprungsland
ita
Ball valve in nickel-plated brass
with full flow for non-corrosive media such as water, compressed air, oils and petroleum.
Thread ISO 7/1 UNI-EN 10226
Temperature -20°C to +140°C
From PN80 (1/4") to PN16 (4)
Housing in brass CW617N UNI-EN 12165
Ball in chrome-plated brass CW614N UNI-EN 12164
Seat and other seals in PTFE
Handle in plastic-coated aluminum AL UNI5076
