    • Riktn.v. Duplomatic NG6 4/2 P-A B-T

    Riktn.v. Duplomatic NG6 4/2 P-A B-T

    Sold without coils. Select the correct coil(s) in the accessories list.

    Artikelnummer:
    DS3-TA/11N-D00
    Förpackningsstorlek:
    1 st
    Minsta beställningskvantitet:
    1 st
    Spole Duplomatic S3 12VDC Din kontakt
    Artikelnummer: C22S3-D12K1/11
    Spole Duplomatic DS3 12VDC Deutsch kontakt ID=22 L=50
    Artikelnummer: C22S3-D12K7/10
    Spole Duplomatic DS3 220DC DIN ID=22 L=50
    Artikelnummer: C22S3-D220K1/12
    Spole Duplomatic DS3 24VDC DIN ID=22 L=50
    Artikelnummer: C22S3-D24K1/11
    Spole Duplomatic DS3 24VDC AMP junior
    Artikelnummer: C22S3-D24K2/11
    Activation
    Solenoid
    Contamination level max.
    20/18/15 - ISO 4406
    Flow rate nominal LMin
    40 lpm
    NG ISO-size
    NG06
    Number of ways/positions
    4/2
    Oil viscocity recommended
    25 cSt
    Pressure T max.
    160 bar
    Surface treatment
    Phosphated (black)
    Temperature max.
    +80 °C
    Temperature min.
    -20 °C
    Förpackningsstorlek
    1 st
    Streckkod
    415621
    Bruttovikt
    Kg
    Nettovikt
    Kg
    Ursprungsland
    swe

    Sold without coils. Select the correct coil(s) in the accessories list.
