Adapter 90 Vridbar Ø16 mm 3/8
Adapter 90 Vridbar Ø16 mm 3/8
Partnumber:
C02471638
Package size:
2 st
Min. order quantity is:
1 st
Angle
90 °
Area of use
Compressed air, Vacuum
Brand Name
Tierre
Dimension A
6.8 mm
Dimension CH
24 mm
Dimension L1
40.8 mm
Dimension L2
33 mm
Dimension T
G 3/8 BSP
Dimension ØD
16 mm
Dimension ØP
26 mm
Material
Brass, PBT-plast, POM(Acetal), Stainless steel, Zinc
Model code
WTRL16G03
Pressure max.
16 bar
Sealing material
NBR
Series
WTR
Temperature max.
+80 °C
Temperature min.
-20 °C
Thread
G 3/8 BSP
Thread outer
G 3/8 BSP
Torque tightening
25 Nm
Tube Insertion Depth
23.6 mm
Tube Tollerance
± 0,15 mm
Vacuum max.
-0.9 bar
Förpackningsstorlek
2 st
Streckkod
170656
Bruttovikt
Kg
Nettovikt
Kg
Ursprungsland
swe
