Press. relief valve 40l/m 70-315bar VEN 06-EN-3-00-XXX

Press. relief valve 40l/m 70-315bar VEN 06-EN-3-00-XXX

Press. relief valve 40l/m 70-315bar VEN 06-EN-3-00-XXX

Partnumber:
810189519
Package size:
1 st
Min. order quantity is:
1 st
Housing NCS06/2--LG2 1/2
Partnumber: 922500113
Housing NCS06/2--LG2 3/8
Partnumber: 922500213
Housing NCS06/2--LG1 1/2
Partnumber: 922500313
Housing NCS06/2--LG1 3/8
Partnumber: 922500413
LINE BODY, NCS 06/2 DG 1/2 NCS06/2-DG 1/2
Partnumber: 922500513
LINE BODY, NCS 06/2 DG 3/8 NCS06/2-DG 3/8
Partnumber: 922500613
Brand Name
Danfoss
Cavity
NCS06/2
Contamination level max.
20/18/14 - ISO 4406
Flow rate nominal LMin
40 lpm
Key size
27 mm
Model code
VEN06-EN-3-00-XXX
Oil viscocity recommended
12 - 54 cSt
Pressure max.
315 bar
Pressure setting max.
315 bar
Pressure setting min.
70 bar
Temperature max.
+100 °C
Temperature min.
-40 °C
Torque tightening
44 - 50 Nm
Package size
1 st
Barcode
374708
Gross weight
0,20 Kg
Net weight
0,20 Kg
Country of origin
ITA
Intrastat code
84812010

Press. relief valve 40l/m 70-315bar VEN 06-EN-3-00-XXX

Product datasheet
