OMT 160 HYDRAULIC MOTOR
Orbital motor for heavy applications. Shaft with taper roller bearings ensures high static and dynamic bearing capacity. Orbit kit with rollers, separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressure. OMT has internal flush valves.
Artikelnummer:
151B3018
Förpackningsstorlek:
1 st
Minsta beställningskvantitet:
1 st
Brand Name
Danfoss
Contamination level max.
22/20/16 - ISO 4406
Continuous power max.
26.5 kW
Continuous rotation max.
625 rpm
Dimension L
190 mm
Dimension L1
16.5 mm
Dimension L2
140 mm
Dimension L3
102 mm
Displacement
161.1 cm3
Drainport
G 1/4 BSP
Holes circle
160 mm
Mounting flange
Square 125
Number of mounting holes
4
Number of outer grooves
6
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Pressure drop continuous max.
200 bar
Recess
125,0 mm
Shaft spline
1.3/8" Z6 PTO
Shaft type
PTO
Temperature ambient max.
+90 °C
Temperature ambient min.
-30 °C
Torque continuous max.
470 Nm
Working ports
G 3/4 BSP
Pakke str.
1 st
Stregkode
333650
Brutto vægt
20,00 Kg
Netto vægt
20,00 Kg
Oprindelsesland
Intrastat varekode
84122981
Orbital motor for heavy applications. Shaft with taper roller bearings ensures high static and dynamic bearing capacity. Orbit kit with rollers, separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressure. OMT has internal flush valves.
