Piston pumps HAWE

Piston pumps HAWE

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Displacement Rotational speed max. Pressure continous max. Rotation direction
V60N-60RDUN-LSN Säätötilavuuspumppu 60cm³/r 60 cm3 2500 rpm 350 bar Right (CW)
V60N-90LDUN-LSN Säätötilavuuspumppu 90cm³/r 90 cm3 2300 rpm 350 bar Left (CCW)
Brand Name
Hydraspecma
Contamination level max.
19/17/13 - ISO 4406
Control
Load sensing
Mounting flange
GER80-4
Number of mounting holes
4
Oil viscocity recommended
10 - 68
Port inlet
Hawe std. 50x50mm
Pressure continous max.
350
Pressure intermittent max.
400
Pressure peak max.
400
Recess
80,0
Rotational speed min.
500
Shaft code
D
Shaft seal material
NBR
Shaft spline
ISO 14 DIN 5462
Shaft type
Spline
Temperature max.
+60
Temperature min.
-40
