Hydraulslang R15 1.1/4'', SAE100R15 ISO3862 WP 420 bar
1 1/4" 31,8x49,7 420bar 265 MSHA
Partnumber:
R15-20
Package size:
1 m
Min. order quantity is:
1 m
Bend radius
265 mm
Brand Name
I.M.M Hydraulics
Diameter inner
31.8 mm
Diameter outer
49.7 mm
Flameresistant
Yes
Hose size
1.1/4 "
Hose type
R15
Hoseapprovals
BV, MSHA
Model code
TFSM015N20
Pressure burst min.
1680 bar
Pressure max.
420 bar
REACH compliant
Yes
RoHs compliant
Yes
Standard ISO
ISO 3862 R15
Standard SAE
SAE 100R15
Temperature intermittent max.
+120 °C
Temperature max.
+100 °C
Temperature min.
-40 °C
Package size
1 m
Barcode
218662
Gross weight
0,91 Kg
Net weight
0,91 Kg
Country of origin
ita
1 1/4" 31,8x49,7 420bar 265 MSHA
Crimp dimensions R15-20
|
Hose type |
Diamter - inch |
Hose coupling type |
Ferrule |
Crimp dimension - mm |
Skiving - int. |
Skiving - ext. |
Operating pressure |
|---|---|---|---|---|---|---|---|
| R15-20 | 1.1/4 | SH20 | SSH4010-20T |
54.2 mm
0.0
0.2 |
22.0 mm
±
|
74.0 mm
±
|
420 |
