    • K2-R-025C-LS-20-20-NN-N-3-C2EK-

    K2-R-025C-LS-20-20-NN-N-3-C2EK-

    -A5N-AAA-NNN-NNN

    Artikelnummer:
    83106376
    Förpackningsstorlek:
    1 pcs
    Minsta beställningskvantitet:
    1 pcs
    AuxMount/EndCap code
    EK
    Brand Name
    Danfoss
    Contamination level max.
    22/18/13 - ISO 4406
    Continuous rotation max.
    3450 rpm
    Displacement
    25 cm3
    Displacement limiter
    Adjustable
    Flange SAE/DIN
    3000 PSI
    Flange inlet
    1.1/2 "
    Flange outlet
    1 "
    Holes circle
    146 mm
    Model
    Frame K2
    Mounting flange
    SAE-B2
    Number of mounting holes
    2
    Number of outer grooves
    13
    Oil viscocity recommended
    9 - 110 cSt
    Port position
    Side
    Pressure continous max.
    260 bar
    Pressure max.
    350 bar
    Recess
    101,6 mm
    Rotation direction
    Right (CW)
    Rotational speed max.
    3750 rpm
    Rotational speed min.
    500 rpm
    Shaft code
    C2
    Shaft diameter
    21,8 mm
    Shaft seal material
    FKM/FPM (Viton®)
    Shaft spline
    13T 16/32 SAE-B
    Shaft type
    Spline
    Temperature intermittent max.
    +115 °C
    Temperature max.
    +104 °C
    Temperature min.
    -40 °C
    Förpackningsstorlek
    1 pcs
    Streckkod
    430823
    Bruttovikt
    16,90 Kg
    Nettovikt
    16,90 Kg
    Ursprungsland
    SK
