OMV 500 HYDRAULIC MOTOR
Orbital motor for heavy applications. Shaft with taper roller bearings ensures high static and dynamic bearing capacity. Orbit kit with rollers - separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressure.
Partnumber:
151B3102
Package size:
0 pcs
Min. order quantity is:
1 pcs
Antal monteringshål
4
Arbetsportar
G 1 BSP
Axel diameter
50 mm
Axel kilspår
14,0 mm
Axeltyp
Cylindrical
Bultcirkel
200 mm
Deplacement
499.6 cm3
Dimension L
230 mm
Dimension L1
37 mm
Dimension L2
175 mm
Dräneringsport
G 1/4 BSP
Föroreningsgrad max.
22/20/16 - ISO 4406
Kont. rotation max.
400 rpm
Kontinuerlig effekt max.
53.5 kW
Moment kontinuerlig max.
1460 Nm
Monteringsfläns
Square 160
Märke namn
Danfoss
Oljeviskositet rekommanderad
20 - 75 cSt
Portplacering
Side
Reces
160,0 mm
Temperatur omgivning max.
+90 °C
Temperatur omgivning min.
-30 °C
Tryckfall kontinuerlig max.
200 bar
Package size
0 pcs
Barcode
5704295162959
Gross weight
35,25 Kg
Net weight
35,25 Kg
Country of origin
Intrastat code
84122981
Orbital motor for heavy applications. Shaft with taper roller bearings ensures high static and dynamic bearing capacity. Orbit kit with rollers - separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressure.
