A15LM22X/71 - Indskruning - ø15L x M22x1.5 - AISI 316Ti
Temperatur/trykreduktion:
-60°C - +20°C = 0%.
+20°C - +50°C = 4,5%.
+50°C - +100°C = 11%.
+100°C - +200°C = 20%.
+200°C - +300°C = 29%.
+300°C - +400°C = 33%.
Varenummer:
A15LM22X/71
Pakke str.:
0 pcs
Min. bestillingsenhed er:
1 pcs
Diameter rör
15 mm
Dimension D2
12 mm
Dimension L1
44.5 mm
Dimension L2
36 mm
Dimension L3
15 mm
Dimension S1
27 mm
Dimension S2
27 mm
Dimension T2
140
Dimension d1
15 mm
Dimension i
14 mm
Gänga T1
M22x1,5
Gänga T2
M22x1,5 mm
Gänga utv. metrisk
M22x1,5
Materialkvalitet
1.4571 / AISI316Ti
Modell kod
XGEV 15 LM 22x1,5
Märke namn
Volz
REACH compliant
Ja
RoHs compliant
Ja
Serie
L
Säkerhetsfaktor
4
Temperatur max.
+400 °C
Temperatur min.
-60 °C
Tillverkningsmaterial
Rustfrit stål
Tryck max.
315 bar
Vinkel
0 °
Package size
0 pcs
Barcode
5704295462714
Gross weight
0,09 Kg
Net weight
0,09 Kg
Country of origin
DEU
Intrastat code
73072910
Temperatur/trykreduktion:
-60°C - +20°C = 0%.
+20°C - +50°C = 4,5%.
+50°C - +100°C = 11%.
+100°C - +200°C = 20%.
+200°C - +300°C = 29%.
+300°C - +400°C = 33%.
