L-fitting adjustable - L-series - Male x Male x MM male counter nut - XLEE-LM

L-fitting adjustable - L-series - Male x Male x MM male counter nut - XLEE-LM

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Diameter pipe Pressure max. Thread outer metric
XLEE06LM Adapter L 06L, Utv-M 10x1, Ställbar 6 mm 315 bar M10x1, M12x1,5
XLEE08LM Adapter L 08L, Utv-M 12x1.5, Ställbar 8 mm 315 bar M12x1,5, M14x1,5
XLEE10LM Adapter L 10L, Utv-M 14x1.5, Ställbar 10 mm 315 bar M14x1,5, M16x1,5
XLEE12LM Adapter L 12L, Utv-M 16x1.5, Ställbar 12 mm 250 bar M16x1,5, M18x1,5
XLEE15LM Adapter L 15L, Utv-M 18x1.5, Ställbar 15 mm 315 bar
XLEE18LM Adapter L 18L, Utv-M 22x1.5, Ställbar 18 mm 250 bar M22x1,5, M26x1,5
XLEE22LM Adapter L 22L, Utv-M 27x2, Ställbar 22 mm 160 bar M27x2, M30x2
XLEE28LM Adapter L 28L, Utv-M 33x2, Ställbar 28 mm 160 bar M33x2, M36x2
XLEE35LM Adapter L 35L, Utv-M 42x2, Ställbar 35 mm 160 bar M42x2, M45x2
XLEE42LM Adapter L 42L, Utv-M 48x2, Ställbar 42 mm 160 bar M48x2, M52x2
Brand Name
Stauff
Corrosion resistance
1200 hours salt spray DIN EN ISO 9227
Material
Steel
Safety factor
4
Series
L
Surface treatment
Zinc-Nickel plated
Temperature max.
+100
Temperature min.
-35
