Filters pneumatic - Norgren F64

SELECT VARIANT

Partnumber	Description	Pressure max.	Thread	Filtration degree
F64C-NND-AD0	Basenhet filter 0,01 my	17 bar	G 1/4 BSP	0,01 my
F64G-2GN-AD3	1/4" filter 40 my	17 bar	G 1/4 BSP	40 my
F64G-2GN-MD3	1/4" filter 40 my	17 bar	G 1/4 BSP	40 my
F64G-3GN-AD3	3/8" filter 40 my	17 bar	G 3/8 BSP	40 my
F64G-3GN-MD3	3/8" filter 40 my	17 bar	G 3/8 BSP	40 my
F64G-4GD-AD3	1/2" filter 40 my	17 bar	G 1/2 BSP	40 my
F64G-4GD-MD3	1/2" filter 40 my	17 bar	G 1/2 BSP	40 my
F64G-4GN-AD3	1/2 filter 40 my	17 bar	G 1/2 BSP	40 my
F64G-4GN-MD3	1/2" filter 40 my	17 bar	G 1/2 BSP	40 my
F64G-6GN-AD3	3/4 filter 40 my	17 bar	G 3/4 BSP	40 my
F64G-6GN-MD3	3/4" filter 40 my	17 bar	G 3/4 BSP	40 my
F64G-NND-AD1	Basenhet filter 5 my	17 bar		5 my
F64G-NND-AD3	Basenhet filter 40 my	17 bar		40 my
F64G-NND-MD1	Basenhet filter 5 my	17 bar		5 my
F64G-NND-MD3	Basenhet filter 40 my	17 bar		40 my
F64G-NNN-AD1	Basenhet filter 5 my	17 bar		5 my
F64G-NNN-AD3	Basenhet filter 40 my	17 bar		40 my
F64G-NNN-MD1	Basenhet filter 5 my	17 bar		5 my
F64G-NNN-MD3	Basenhet filter 40 my	17 bar		40 my
F64H-3GD-AD0	3/8 filter 0,01 my	17 bar	G 3/8 BSP	0,01 my
F64H-4GD-AD0	1/2 filter 0,01 my	17 bar	G 1/2 BSP	0,01 my
F64H-NND-AD0	Basenhet filter 0,01 my	17 bar		0,01 my
F64H-NND-MD0	Basenhet filter 0,01 my	17 bar		0,01 my
F64H-NNN-AD0	Basenhet filter 0,01 my	17 bar		0,01 my

Brand Name

Norgren

Material

Zinc

Pressure max.

Sealing material

NBR

Temperature min.

-20
