    • Flow divider valves Danfoss CP342

    Flow divider valves Danfoss CP342

    Välj variant
    VÄLJ VARIANT
    VÄLJ VARIANT
    Artikelnummer Beskrivning Pressure max. Flow min. regulated Flow max. regulated Cavity
    137551-CP342 Flow Divider ventil 23l/m 1:1 CP342-3-U-0-0303 450 bar 23 lpm 23 lpm CP16-4
    137698 Flow Divider ventil 45l/m 1:1 CP342-3-U-0-0606 450 bar 45 lpm 45 lpm CP16-4
    137789-CP342 Flow Divider ventil 68l/m 1:1 CP342-3-U-0-0909 450 bar 68 lpm 68 lpm CP16-4
    138300-CP342 Flow Divider ventil 114l/m 1:1 CP342-3-U-0-1515 450 bar 114 lpm 114 lpm CP16-4
    139663-CP342 Flow Divider ventil 121l/m 5:3 CP342-3-U-0-2012 450 bar 121 lpm 121 lpm CP16-4
    139664-CP342 Flow Divider ventil 114l/m 1:2 CP342-3-U-0-1020 450 bar 114 lpm 114 lpm CP16-4
    139795 Flow Divider ventil 91l/m 1:1 CP342-3-U-0-1212 450 bar 91 lpm 91 lpm CP16-4
    H140675 Flow Divider ventil 38l/m 1:1 CP342-3-U-0-0505 450 bar 38 lpm 38 lpm CP16-4
    Brand Name
    Danfoss
    Cavity
    CP16-4
    Contamination level max.
    20/18/14 - ISO 4406
    Flow rate nominal LMin
    150
    Oil viscocity recommended
    12 - 54
    Pressure compensated
    Yes
    Pressure max.
    450
    Sealing material
    NBR
    Temperature max.
    +100
    Temperature min.
    -40
    Torque tightening
    122 - 136
