Orbital motors M+S MS series

Orbital motors M+S MS series

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Displacement Shaft diameter Shaft type Continuous power max.
MS100CP MOTOR***M+S 100cc cyl32 SAE-A, 100 cm3 32 mm Cylindrical 18 kW
MS100SHP Motor M+S 100cc spl31.75 SAE-A
MS125CP MOTOR***M+S 125cc cyl32 SAE-A, 125 cm3 32 mm Cylindrical 18 kW
MS160CP MOTOR***M+S 160cc cyl32 SAE-A, 160 cm3 32 mm Cylindrical 16.5 kW
MS160SHP MOTOR ***** M+S 160cc Spl31,75 160 cm3 31,75 mm Spline 16.5 kW
MS160SLP Motor 160cc,
MS200CP Motor***M+S 200cc cyl32 SAE-A, 200 cm3 32 mm Cylindrical 16.5 kW
MS200SHP MOTOR m+s 200 cm3 31,75 mm Spline 16.5 kW
MS250CP MOTOR***M+S 250cc cyl32 SAE-A, 250 cm3 32 mm Cylindrical 14.5 kW
MS250KP MOTOR*****M+S 250cc 1:10 SAE-A 250 cm3 Tapered 14.5 kW
MS250SLP Motor 250cc,
MS315CP Motor***M+S 315cc cyl32 SAE-A, 315 cm3 32 mm Cylindrical 15 kW
MS315CULLP Motor M+S 315cc Cyl32 SAE A 4H U seal LowLeakage Blackpaint
MS315SHP Motor*****M+S 315cc spl 31.75, 315 cm3 31,75 mm Spline 15 kW
MS400CP Motor***M+S 400cc cyl32 SAE-A, 400 cm3 32 mm Cylindrical 11 kW
MS80CP Motor****M+S 80cc cyl32 SAE-A, 80 cm3 32 mm Cylindrical 15.5 kW
MS80SLP Motor***M+S 80cc PTO 6B SAE-A, 80 cm3 15.5 kW
MSF315COP Motor M+S 315cc cyl31.75 315 cm3 31,75 mm Cylindrical 15 kW
MSS100P MOTOR*****M+S 100cc 'short' 100 cm3 18 kW
MSS125P Motor M+S 125cc 100 'short' 125 cm3 18 kW
MSS250P Motor M+S 250cc 100 'short' 250 cm3 Spline 14.5 kW
MSS315P Motor M+S 315cc 100 Short G182 314.9 cm3 Spline 15 kW
MSS400P Motor***M+S 400cc 100 'Short' 400 cm3 11 kW
MSW160KP Motor M+S 160cc 1:10 125 160 cm3 Tapered 16.5 kW
MSW200CP Motor M+S 200cc cyl32 125 200 cm3 32 mm Cylindrical 16.5 kW
MSW315CP Motor M+S 315cc cyl32 315 cm3 32 mm Cylindrical 15 kW
MSW315KP MOTOR***M+S 315cc 1:10 125 4H, 315 cm3 Tapered 15 kW
MSW80CP Motor***M+S 80cc cyl32 125 4H, 80 cm3 32 mm Cylindrical 15.5 kW
Brand Name
Hydraspecma
Contamination level max.
-/20/16 - ISO 4406
Filtration degree
25
Oil viscocity recommended
20 - 75
Temperature max.
+82
Temperature min.
-40
