Adapter för akumulator

The STAUFF SDAA adapter is designed for membrane accumulators and enables quick, safe connection of a PT-RF pressure sensor for measuring nitrogen filling pressure - without emptying the accumulator. The adapter provides a tight and stable connection to the nitrogen valve, so the measurement can be performed without loss of gas and without affecting system operation.

Features

  • For membrane accumulators (SDAA type)
  • Enables pressure measurement with PT-RF sensor (optional)
  • Quick mounting directly on nitrogen valve (M8)
  • No pressure loss during connection
  • Robust steel construction with zinc/nickel coating
  • Maintenance-free

Artikelnummer:
SDAA-M08-B04-W3

Förpackningsstorlek:
1 st

Minsta beställningskvantitet:
1 st
Brand Name
Stauff

Connection Thread BSP
1/4" BSP

Connection Thread MM
M8

Material
Steel

Pressure max.
400 bar

Sealing material
NBR

Surface treatment
Zinc-Nickel plated
Förpackningsstorlek
1 st

Streckkod
421342

Bruttovikt
Kg

Nettovikt
Kg

Ursprungsland
deu

The STAUFF SDAA adapter is designed for membrane accumulators and enables quick, safe connection of a PT-RF pressure sensor for measuring nitrogen filling pressure - without emptying the accumulator. The adapter provides a tight and stable connection to the nitrogen valve, so the measurement can be performed without loss of gas and without affecting system operation.

Features

  • For membrane accumulators (SDAA type)
  • Enables pressure measurement with PT-RF sensor (optional)
  • Quick mounting directly on nitrogen valve (M8)
  • No pressure loss during connection
  • Robust steel construction with zinc/nickel coating
  • Maintenance-free
