Rev. counter PPC04/12 With 3 mtr cable
The Sensor-PPC-04/12-SDS-CAB rotational speed sensor allow non-contact speed measurement of rotating components. The sensor is based on an opto-electrical measurement principle that determines the rotational speed with high accuracy using a reflecting strip on the shaft.
The contact rotational speed measurement is achieved by using a contact adaptor attached to the sensor, which touches the rotating component during the measurement process. This method ensures highly accurate results. For particularly small areas, a focusing adaptor can be used to facilitate the measurement.
Note:
- The analogue rotational speed sensor can only be used with analogue dataloggers
- It’s not recommended to extend the sensor beyond the 2-meter permanent cable connection provided with the sensor.
Partnumber:
PPC-04/12-SDS-CAB-CAL
Package size:
1 st
Min. order quantity is:
1 st
Märke namn
Stauff
Rotationshastighet max.
10000 rpm
Rotationshastighet min.
20 rpm
Sensor typ
SR
Temperatur omgivning max.
+85 °C
Temperatur omgivning min.
-25 °C
Utgående signal max.
3 V
Utgående signal min.
0 V
Wirelängd
3 m
Förpackningsstorlek
1 st
Streckkod
426390
Bruttovikt
0,22 Kg
Nettovikt
0,22 Kg
Ursprungsland
DEU
Intrastat artikelkod
90261021
The Sensor-PPC-04/12-SDS-CAB rotational speed sensor allow non-contact speed measurement of rotating components. The sensor is based on an opto-electrical measurement principle that determines the rotational speed with high accuracy using a reflecting strip on the shaft.
The contact rotational speed measurement is achieved by using a contact adaptor attached to the sensor, which touches the rotating component during the measurement process. This method ensures highly accurate results. For particularly small areas, a focusing adaptor can be used to facilitate the measurement.
Note:
- The analogue rotational speed sensor can only be used with analogue dataloggers
- It’s not recommended to extend the sensor beyond the 2-meter permanent cable connection provided with the sensor.
