Pump Kawasaki 45cc vä rot SAE B2-SPL.15T med PTO

Pump Kawasaki 45cc vä rot SAE B2-SPL.15T med PTO

Pump Kawasaki 45cc vä rot

Varenummer:

K3VL45B-1NLSM-L1

Pakke str.:

1 st

Min. bestillingsenhed er:

1 st

Specifikationer
Dimensioner og forsendelse

Brand Name

Kawasaki

Control

Load sensing

Displacement

45 cm3

Flange inlet

1.1/2 "

Flange outlet

1 "

Holes circle

14.3 mm

Mounting flange

SAE-B2

Number of mounting holes

Oil viscocity recommended

10 - 1000 cSt

Port position

Side

Pressure continous max.

320 bar

Pressure intermittent max.

350 bar

Rotation direction

Left (CCW)

Rotational speed max.

2700 rpm

Shaft diameter

25,4 mm

Shaft spline

15T 16/32 SAE-BB

Shaft type

Spline

Temperature max.

+95 °C

Temperature min.

-20 °C

Pakke str.

1 st

Stregkode

224132

Brutto vægt

28,00 Kg

Netto vægt

28,00 Kg

Oprindelsesland

gbr

Produkt information

Pump Kawasaki 45cc vä rot

Product datasheet
